RSA6106A Tektronix Spectrum Analyzer
Frequency range: 9 kHz-6.2 GHz 20 dBm 3rd Order Intercept at 2 GHz, Typical Displayed Average Noise Level –151 dBm/Hz at 2 GHz (–170 dBm/Hz, Preamp On, typical) enables Low-level Signal Search ±0.5 dB Absolute Amplitude Accuracy to 3 GHz for High Measurement Confidence Fully Preselected and Image Free at All Times for Maximum Dynamic Range at Any Acquisition Bandwidth Fastest High-resolution Sweep Speed: 1 GHz sweep in 10 kHz RBW in less than 1 second
REQUEST A QUOTE
Stock
|
Detail
|
Option
|
Download
|
Video
RSA6106A Tektronix Spectrum Analyzer
01: Internal PreAMP, 10MHz to 3GHz 30dB gain, 4dB noise figure at 2GHz typical / 02: 1GB Memory, Frequency Mask Trigger / 07: DVD-RW / 110: 110 MHz Capture Bandwidth / 20: Advanced Signal Analysis / 21: General Purpose Digital Modulation Analysis /
Price: CALL
Detail
rements help you Characterize Components and Systems: Channel Power, ACLR, Power vs. Time, CCDF, OBW/EBW, and Spur Search AM/FM/PM Modulation and Audio Measurements (Opt. 10) Phase Noise and Jitter Measurements (Opt. 11) Settling Time Measurements, Frequency, and Phase (Opt. 12) Pulse Measurements (Opt. 20) – Over 20 Vector and Scalar Parameters including Rise Time, Pulse Width, Pulse-to-Pulse Phase provide Deep Insight into Pulse Train Behavior General Purpose Digital Modulation Analysis (Opt. 21) provides Vector Signal Analyzer Functionality for Over 20 Modulation Types Flexible OFDM analysis of 802.11a/g/j and WiMAX 802.16-2004 Applications Spectrum Management – Find Interference and Unknown Signals Radar/EW – Full Characterization of Pulsed and Hopping Systems Characterize Radar and Pulsed RF Signals RF Debug – Components, Modules, and Systems Radio/Satellite Communications – Analyze Time-variant Behavior of Cognitive Radio and Software-defined Radio Systems EMI Diagnostics – Increase Confidence that Designs will Pass Compliance Testing The RSA6114A replaces conventional high-performance signal analyzers, offering the measurement confidence and functionality you demand for everyday tasks. A typical 20 dBm TOI and –151 dBm/Hz DANL at 2 GHz gives you the dynamic range you expect for challenging spectrum analysis measurements. All analysis is fully preselected and image free. The RSA6114A uses broadband preselection filters that are always in the signal path. You never have to compromise between dynamic range and analysis bandwidth by ‘switching out the preselector’. A complete toolset of power and signal statistics measurements is standard, including Channel Power, ACLR, CCDF, Occupied Bandwidth, AM/FM/PM, and Spurious measurements. Available Phase Noise and General Purpose Modulation Analysis measurements round out the expected set of high-performance analysis tools.
Option
Option Description
01 Internal PreAMP, 10MHz to 3GHz 30dB gain, 4dB noise figure at 2GHz typical
02 1GB Memory, Frequency Mask Trigger
05 Digital IQ Output and 500MHz Analog IF Output
07 DVD-RW
110 110 MHz Capture Bandwidth
20 Advanced Signal Analysis
200 Advanced Triggers and Swept DPX
21 General Purpose Digital Modulation Analysis
