Additional Features: Frequency Range: 9 kHz - 40 GHz Dynamic Range: +30 dBm - -132 dBm Input Impedance: 50 ohms Residual FM: <=(60 Hzp-p xN)/100ms Resolution Bandwidth: 1 kHz - 3 MHz Video Bandwidth: 10 Hz - 3 MHz Frequency span accuracy: ±1 Noise level: -104 dBm/RBW 1 kHz @26.5 GHz Refresh rate: 20 traces/second (Typical) 50 µs high-speed zero span sweep (Option) 1 Hz resolution frequency counter EMC measurement functions 6 dB RBW: 9 kHz/120 kHz/1 MHz (200 Hz optionally available) Built-in QP detector Built-in antenna correction factor table AM/FM audio demodulation function Digital mobile communications measurement functions: OBW, ACP, Spurious, Total/Channel/Average power, Default setup function for power measurement Highest-Class Noise Level Expansion of Measurement Frequency Band Variety of Measurement Functions The R3182 is a low-cost portable spectrum analyzer capable of performing direct input measurements at a maximum frequency of 40 GHz. Adopting newly designed RF circuitry, the R3182 aim for improved basic performance with their 40 GHz direct input capability.  Further, the R3182 achieves "best-in-class" performance for average display noise levels of -106 dBm (at 40 GHz, RBW 1 kHz), and SSB phase noise levels of -85 dBc/Hz (at 40 GHz, 20 kHz offset). Operating frequencies for radio communications have increasing tendency to shift to higher frequencies. Accordingly, the R3182 has been developed as personal-use spectrum analyzers capable of use in a wide range of applications from development to manufacturing of high frequency modules, devices, etc.
