Frequency Range: 9 kHz to 26.5 GHz Input Impedance: 50 Ohms Sweep Time: 1 us to 1500sec Resolution Bandwidth: 10 Hz to 10 MHz Resolution Bandwidth Steps: 1/2/3/5 Video Bandwidth: 1 Hz to 10 MHz Video Bandwidth Steps: 1/2/3/5 Minimum Single-Side-Band Noise: -129 dBc/Hz to -79 dBc/Hz Displayed Average Noise: -138 dBm to -84 dBm Maximum Dynamic Range: 150 dB Trigger Source External,Internal Trigger Modes Freerun, TTL Modulation: AM,FM The FSEM30 spectrum analyzers from Rohde & Schwarz have been optimized both for general-purpose measurements and meeting the stringent requirements of testing advanced digital communication systems. High measurement speed, future-proof modular design and excellent characteristics put the analyzers right at the top of today's market–at an attractive price.

Option	Description
B10	TG 7GHz
B15	CoComputer Function
B16	Ethernet Interface
B17	2nd IEC/IEEE-Bus Interface for FSE
B21	External Mixer
B4	Low Phase Noise and OCXO
B5	FFT-Bandwidth 1Hz-1KHz
B7	Vector Signal Analyzer
B9	Tracking Generator with I/Q Modulator
