Additional Features: DC Voltage Range: 0 to ±1020V DC Current Range: 0 to ±11A Resistance Range: 0 to 329.999 MΩ AC Voltage Range: 1 mV to 1020V AC Current Range: 29 mA to 11A Capacitance Range: 0.33 nF to 1.1 mF DC Power Range: 109 mW to 11 kW AC Power Range: 109 mW to 11 kW Phase Power Range: 0 to ± 179.99° Frequency Range: 0.01 Hz to 2.0 MHz These calibrators were designed to cover a very wide range of medium accuracy electrical measurement devices including: Handheld and bench multimeters Oscilloscopes Wattmeters Analog,volt/ohm/amp/watt instruments Electronic thermometers Data loggers Strip chart recorders Power harmonics analyzers Process calibrators Current clamps and related instruments The Fluke 5500A is a revolutionary product that addresses a wide cross-section of your electrical calibration work load. It sources direct voltage and current, alternating voltage and current with multiple waveforms and harmonics, two simultaneous voltage outputs or voltage and current, and simulates power with phase control, resistance, capacitance, thermocouples, and RTDs. The Oscilloscope Calibration options of the 5500A provide level sine wave, fast edge, time mark, and amplitude signals for calibration of oscilloscopes up to 600 MHz.
