N1914A Agilent RF Power Meter
Frequency range of 9 kHz to 110 GHz (sensor dependent)
Wide dynamic range of -70 to +44 dBm (sensor dependent)
Speed improvement by 2X for E-Series sensors: up to 400 readings/sec
Go beyond GPIB with LAN LXI-C and USB connectivity
Enhanced user interface with high-resolution color display and numeric keypad
Code-compatible with 438A power meter
Increased measurement channels: up to three channels with two additional U2000 Series power sensors connected using the optional USB hosts
Automated frequency/power sweep measurements with the optional external trigger in/out feature
The Agilent N1914A offers powerful features, yet is code compatible with the popular Agilent E4418B and Agilent E4419B EPM power meters. With a reading rate at twice the speed (E-Series power sensors), flexibility of GPIB, LAN LXI-C or USB connectivity, making average power measurements has never been easier. You can connect two additional Agilent U2000 Series power sensors to the power meter via the optional USB hosts, transforming the Agilent N1914A into a 3-channel or 4-channel power meter. Plus, the new color display lets you view and analyze test data more easily.
