Key performance specifications

• DC to 20 MHz bandwidth
• 150 ARMS maximum current capability
• 500 a peak pulse current capability
• High accuracy with typically less than 1% DC gain error
• Accurately measures current levels as low as 5 mA

Key features

• Easy-to-Use and accurate AC/DC current measurements
• Connects directly to oscilloscopes with the TekVPI™ probe interface
• Low noise and DC drift
• Provides automatic units scaling and readout on the oscilloscope's display
• Remote GPIB/USB probe control through the oscilloscope
• Split-core probe head construction allows easy connection to conductors
• Easy to degauss and autozero
• Setup controls and probe status and diagnostic indicators are provided on both the probe hardware and through an Easy-to-Access scope UI display menu

Applications

• Power supplies
• Semiconductor devices
• Power inverters/converters
• Electronic ballasts
• Industrial/consumer electronics
• Motor drives
• Transportation systems
