The LeCroy WaveRunner®  Xi-A is the most powerful and capable scope available in its class. Basic system validation using advanced triggers, fast viewing modes, measurement parameters, or serial decodes is simple and easy. Advanced debug, multi-domain analysis, and waveshape analysis are possible with tools unique to WaveRunner Xi-A. Optional application packages help you make sense of well-defined problems. WaveRunner Xi-A is the most complete “problem solving” oscilloscope from 400 MHz to 2 GHz with great performance, an unbelievable big display/small footprint form factor, and a multitude of fast viewing, SMART/serial data triggering, scanning, and WaveShape Analysis capabilities for fast or slow signals.

The WaveRunner MXi-A not only provides the performance and tools

required to debug and validate your signals, it goes deeper into your testing to help you understand the causes of complex problems. The WaveRunner MXi-A oscilloscopes provide all of the powerful debug and analysis tools of the Xi-A models, with the addition of advanced Math and measurements, jitter and timing analysis, and customized math and measurements. The WaveRunner MXi-A provides all of the essential tools for efficient validation and debug.

400 MHz – 2 GHz Analog BandwidthsAdvanced Math and Measurement Capabilities, including CustomizationJitter and Timing AnalysisBright, 10.4" DisplayOnly 15 cm (6") DeepDedicated Cursor KnobsTouch Screen with Built-in StylusEnhanced Understanding of Serial Data Signals - Trigger on I2C, SPI, UART, RS-232, LIN, CAN, or FlexRay serial data patternsPowerful Triggers Isolate Events - An extensive collection of SMART, Serial, and Digital (MS Series) triggers enables users to quickly and easily isolate events of interest (some optional)WaveStream™ Fast Viewing ModeAdvanced Acquisition ModesCompletely Customizable - Quickly create your own measurement parameters or math functions using Excel, MATLAB,® or VBScripts (some capability optional)WaveScan™ Advanced Search and AnalysisAdvanced Application Packages - Use a variety of application packages to provide detailed, fast solutions for specific problemsFast Long Memory with Front Panel Zoom ControlsBeyond Time Domain Analysis - Amplify your understanding with multidomain analysis of your signalsIntegrated Tool Sets - LeCroy math, measure, and analysis tools are tightly integrated with basic scope operationsComplete Probing Solutions - A wide variety of active FET probes, current probes, differential probes, and HV probes, with complete tip and ground accessories make it easy to probe your signalsMixed Signal Oscilloscope OptionPower/Amplifier Measurements - Excellent overdrive recovery and signal integrity make WaveRunner Xi-A ideal for high-voltage switching loss, conduction loss, ripple, switching power supply, and other amplifier measurementsTiming Characterization - Extensive triggers allow fast event isolationSlow/High-speed Signal Mix - Long memory, HFREJ trigger coupling, and built-in noise filtering enable fast understanding of signal behavior in circuits with a mix of slow-speed (sensor, actuator, power supply, mechanical) and high-speed signals

Note: The 204MXi was originally released in April 2008. LeCroy released the 204MXi-A in February 2009.
