FSEM30(1079.8500.30) Rohde & Schwarz Spectrum Analyzer
Frequency Range: 9 kHz to 26.5 GHz Input Impedance: 50 Ohms Sweep Time: 1 us to 1500sec Resolution Bandwidth: 10 Hz to 10 MHz Resolution Bandwidth Steps: 1/2/3/5
REQUEST A QUOTE
Stock
|
Detail
|
Option
|
Download
|
Video
Detail

Additional Features:

  • Frequency Range: 9 kHz to 26.5 GHz
  • Input Impedance: 50 Ohms
  • Sweep Time: 1 us to 1500sec
  • Resolution Bandwidth: 10 Hz to 10 MHz
  • Resolution Bandwidth Steps: 1/2/3/5
  • Video Bandwidth: 1 Hz to 10 MHz
  • Video Bandwidth Steps: 1/2/3/5
  • Minimum Single-Side-Band Noise: -129 dBc/Hz to -79 dBc/Hz
  • Displayed Average Noise: -138 dBm to -84 dBm
  • Maximum Dynamic Range: 150 dB
  • Trigger Source External,Internal
  • Trigger Modes Freerun, TTL
  • Modulation: AM,FM

The FSEM30 spectrum analyzers from Rohde & Schwarz have been optimized both for general-purpose measurements and meeting the stringent requirements of testing advanced digital communication systems. High measurement speed, future-proof modular design and excellent characteristics put the analyzers right at the top of today's market–at an attractive price.

Option
Option Description
B4 Low Phase Noise and OCXO
B5 FFT-Bandwidth 1Hz-1KHz
FSE-B10(1066.4769.02) TG 7GHz
FSE-B15(1073.5696.03) Controller for FSE
FSE-B17(1066.4017.02) 2nd IEC/IEEE Bus Interface for FSE
FSE-B3(1073.5244.02)
FSE-B7(1066.4317.02) Vector Signal Analyzer
