Features: Analog Bandwidth: 8 GHz  Analog Sample Rate –2/4 Channels: 25 GS/s  Standard Memory–Analog + Digital: 62 MS  Analog Channels: 4 Logic Channels: 16 16 Logic Channels with 80 ps Timing Resolution for Debug of digital and analog signals (MSO70000 Series only) Unique iCapture® capability enables viewing analog characteristics of digital channels with single probe connection 6.25 Gb/s Real-time Serial Trigger – Assures triggering on the first instance of a specified NRZ or 8b/10b pattern to allow isolation of pattern-dependent effects Application Support for High-speed Serial Industry Standards, wideband RF, Power supplies, and memory – Enables standard-specific certification, measurement automation, and ease of use High-speed serial industry standards compliance SignalVu RF and vector signal analysis DDR memory bus analysis Applications Design verification including signal integrity, jitter, and timing analysis Design characterization for high-speed, sophisticated designs Certification testing of serial data streams for industry standards Memory bus analysis and debug Prototype turn-on and power supply verification Research and investigation of transient phenomena Production testing of complex systems Spectral analysis of transient or wide-bandwidth RF signals The Tektronix MSO70804C is 8 GHz, 4 Channel, 25 GS/s, 62.5 MPts Mixed Domain Oscilloscope. Engineers rely on an oscilloscope throughout their design cycle, from prototype turn-on to production testing. The MSO/DPO70000 Series oscilloscopes' unique capabilities combined with exceptional signal acquisition performance and analysis accelerate your measurement tasks. The image is for reference only. See product specification for details.

Option	Description
2XL	20 Meg Max 20M/CH
5XL	62.5M memory on all four channels
ASM	Advanced Search & Mark
DDRA	DDR Analysis
DJA	Jitter and Eye Diagram Tools - Advanced
ET3	Ethernet Compliance Test Software
HT3	HDMI Compliance Test Software
MTH	Serial Mask Testing
PCE	PCI Express Essentials
PTD	Protocol Decoding for 8b/10b-encoded Serial Signals
PTH1	3.125Gb/s Serial Pattern Trigger
SR-810B	8b/10b Serial Analysis
SR-CUST	Custom Serial Analysis
SR-EMBD	Embedded Serial Triggering and Analysis (I2C, SPI)
SR-USB	USB Serial Triggering and Analysis
SST	SATA and SAS Analysis Software Module for RT-Eye Analysis Software
ST
STU	6.25Gb/s Serial Pattern Trigger
TDSET3	Ethernet Compliance Test Software
TDSPTD	Protocol Trigger and Decode
TDSUSB2	USB2.0 Compliance Test Package
USB	USB 2.0 Compliance Test Software
USB2	TekExpress USB2
