Bandwidth: 1 GHz  4 Channels 20 GSa/s max. sample rate 40 Mpts per channel memory 3-in-1 instrument: oscilloscope, logic analyzer, and protocol analyzer Advanced Triggering 15” XGA display makes it easier to view analog, digital and serial signals. Comprehensive built-in information system gives you fast answers to your questions. The task-oriented setup guide provides step-by-step instructions for several measurement procedures. Touchscreen display comes standard for mouse-free operation. Drag-and-drop measurements from the measurement bar provide an intuitive way to make a measurement on a particular cycle of your waveform. Capture longer time periods with up to 1 Gpts memory depth See precise representation of your signal with 20 GSa/s maximum sample rate The Agilent Infiniium DSO9104A offers a bandwidth of 1 GHz, is equipped with a large 15” XGA LCD display, comes in a whisper-quiet package that is just 9” (23 cm) deep and weighs only 26 pounds (11.8 kg). High-performance scope channels ensure superior viewing of signals under test. The DSO9104A incorporates a powerful, feature-packed Infiniium oscilloscope with responsive deep memory. With 40 Mpts memory per channel and 20GSa/s sample rate, you can capture long time periods while retaining fast sample rates. Fast update rates mean your scope stays responsive with deep memory on, ensuring precise representation of analog signals. Scope: The powerful features of our Infiniium Series oscilloscopes coupled with superior specifications give you precise signal representation. Logic analyzer: Fast deep-memory digital channels let you see critical data values and timing relationships. MSO models add 16 high-speed timing channels with standard 128 Mpts digital memory, allowing you to retain fast 2 GSa/s sample rates over long periods of time. Choose MSO9104A. Protocol analyzer: The world’s first scope-based protocol viewer with multi-tab viewing. Quickly drill and move between protocol and physical layers. Protocol analyzer Add protocol analysis capability to your scope for: Quickly move between physical and protocol layer information using the time-correlated tracking marker. Display protocol content using waveform symbols and the industry’s first multi-tab protocol viewer.  The packets tab shows a high level view of the packet over time. Protocol-level triggering makes it easy to isolate events with pinpoint accuracy. Export screen shots and waveforms in numerous industry-standard formats. In addition, the 9000 Series supports compatibility with the following: MATLAB Basic and Advanced (add as 061 and 062 on new scope orders) IVI COM driver for application development environments such as Visual Studio, Agilent VEE, NI LabView and MATLAB instrument control toolbox. IntuiLink tool bars and data capture. LXI Class C including built-in Web control NI LabView PnP and IVI drives Agilent offers an innovative family of probes that are engineered for signal access and measurement accuracy. Whether you’re looking for simple passive probes, the high bandwidth and low loading of an active probe, or specialty probes for current or high voltage, we can meet your needs. Our innovative accessories allow reliable connection to challenging components like small pitch devices, surface mount ICs, and DDR BGA packages – even hands free! The image is a representation of selection. See specifications for product details.

Option	Description
002
021
800
