Bandwidth: 1 GHz 4 Channels 10/5 GS/s (2/4 channels) Record Length: 25M-4 Channel, 50M-1 or 2 Channels Rise Time: 350 ps Up to 250 megapoint record length with MultiView zoom™ >250,000 wfms/s maximum waveform capture rate with FastAcq™ acquisition FastFrame™ segmented memory acquisition mode with up to 290,000 segments and >310,000 waveforms per second capture rate Standard 10 MΩ passive voltage probes with less than 4 pF capacitive loading and 500 MHz or 1 GHz analog bandwidth >11 bits vertical resolution using HiRes sampling User-selectable bandwidth limit and DSP filters for lower noise and better measurement accuracy Key analysis features Wave inspector® controls provide easy navigation and automated search of waveform data Suite of advanced triggers, with standard Visual Trigger and Search 53 automated measurements, selectable filtering, waveform math and FFT analysis Waveform histogram, eye diagram, TIE (jitter/timing) measurement and analysis User-definable math using MATLAB, Visual Studio and Excel Optional analysis for memory, advanced jitter, serial data, power and Wideband RF Key protocol features Trigger and decode options for mid-speed (100 Mb/s to 1 Gb/s) buses Trigger and decode options for low-speed (<10 Mb/s) buses Compliance test options for USB2.0, Ethernet, USB power, MOST, BroadR-Reach Mask testing on communication, computing and video standards  Standard Accessories: TPP0500/B: One Passive Voltage Probe per Analog Channel (1 GHz, 10X, 3.9 pF) Front Cover Touchscreen Stylus User Manual (please specify language when ordering) Advanced Search and Mark, DPOJET Essentials, Visual Trigger and Search, Limit Test, and SR-CUST Custom serial analysis license all included standard Accessory Pouch, Mouse Calibration certificate documenting measurement traceability to National Metrology Institute(s), Z 540-1 compliance and ISO9001 Power Cord (please specify power plug option when ordering) One-Year Warranty The Tektronix DPO5104B oscilloscope provides exceptional signal fidelity, with a 1 GHz bandwidth and a 10GS/s sample rate, along with advanced analysis and math capabilities, on your bench and in your lab. Run Windows®-based analysis software right on the oscilloscope. Point and click Visual Triggers enable you to capture complex signals with ease.

Option	Description
2RL	50 Meg Max 25M/CH
ASM	Advanced Search & Mark
CMENET3	Tek express ethernet automated 10/100/1000 base-T solution
DJA	Jitter and Eye Diagram Tools - Advanced
DJE	Jitter and Eye Diagram Tools - Essentials
LT	Limit Test
PWR	Power measurement and analysis
SR-AUTO	Automotive Serial Trigger & Analysis(CAN/LIN/FlexRay)
SR-CUST	Custom Serial Analysis
TDSET3	Ethernet Compliance Test Software
TDSUSB2	USB2.0 Compliance Test Package
VET	Visual Trigger and Search
