Lower DUT loading effects with ≤0.8 pF input capacitance and 40 kΩ input resistance Versatile DUT connectivity for attaching to small SMDs Preserves oscilloscope bandwidth at the probe tip for DPO7000 and DPO4000 Series Oscilloscope models up to 2.5 GHz ≥2.5 GHz Probe Bandwidth <140 ps Rise Time ≤0.8 pF Input Capacitance 40 kΩ Input Resistance –4 V to +4 V Input Dynamic Range –10 V to +10 V DC Input Offset Range Max Input Voltage (Non-destruct): ±30 V (DC + pkAC) Small Compact Probe Head for Probing Small Geometry Circuit Elements DUT Attachment Accessories Enable Connection to SMDs As Small As 0.5 mm Pitch Robust Design for ReliabilityVersatile Mechanical Performance:
